Plasser KSP-2002 Ballast Regulator & Stabiliser – 2 Available
Listing Status: Available
Two Plasser KSP-2002 ballast regulator and track stabiliser machines are available, configured for 1,067 mm gauge operation.
The machines are powered by KHD F12L 413FW air-cooled 12-cylinder diesel engines rated at 240 kW (320 hp) at 2,300 rpm.
Tare weight is 46.2 tonnes, with an operating weight of 59.2 tonnes. Overall machine dimensions are 15,600 mm long, 2,950 mm wide and 4,000 mm high, with an overall coupled length of 16,900 mm including automatic couplers.
Running gear dimensions include 9,000 mm bogie centres, a 1,300 mm bogie wheelbase and 730 mm wheel diameter. Fuel capacity is 550 litres.
Axle loads are 10.2 tonnes front and 12.9 tonnes rear at tare weight, increasing to 15.0 tonnes front and 14.6 tonnes rear at operating weight.
Specifications
General
Engine & Driveline
Dimensions & Running Gear
Additional Details
Engine operating data
- Rated speed: 2,300 rpm
- Maximum engine speed: 2,500 rpm
- Working engine speed: 1,900 rpm
